Large Fragment Instrument Set
- Comprehensive large fragment instrument set for orthopedic surgeries
- Includes various drill bits, tap guiders, elevators, forceps, and retractors
- Comes with a depth gauge, screwdriver, bone holding forceps, and other essential tools
- All instruments packed in a durable aluminum box for easy storage and transportation
- SKU
- 4200-02
- Brand
- Orthopromed
- Warehouse
- US · UK · NL
- Availability
- In stock
- ✓ Warranty included
- ✓ Worldwide shipping
Clinical overview
Product overview
| 1 | 4200-0201 | Neutral and Load Drill Guide Φ3.2 | 1 |
| 2 | 4200-0202 | Drill & Tap Guider (Φ4.5/Φ6.5) | 1 |
| 3 | 4200-0203 | Drill & Tap Guider (Φ3.2/Φ4.5) | 1 |
| 4 | 4200-0204 |  Drill Bit (Φ4.5*115mm) | 1 |
| 5 | 4200-0205 |  Drill Bit (Φ4.5*115mm) | 1 |
| 6 | 4200-0206 |  Drill Bit (Φ3.2*115mm) | 1 |
| 7 | 4200-0207 |  Drill Bit (Φ3.2*115mm) | 1 |
| 8 | 4200-0208 | Depth Gauge (0-90mm) | 1 |
| 9 | 4200-0209 | Periosteal Elevator 15mm | 1 |
| 10 | 4200-0210 | Obilique Reduction Forcep (230mm) | 1 |
| 11 | 4200-0211 | Periosteal Elevator 8mm | 1 |
| 12 | 4200-0212 | Sharp Reduction Forcep (200mm) | 1 |
| 13 | 4200-0213 | Silicon Handle Screwdriver Hexagonal 3.5mm | 1 |
| 14 | 4200-0214 | Self-centering Bone Holding Forcep (270mm) | 2 |
| 15 | 4200-0215 | Retractor Width 40mm/18mm | 1 |
| 16 | 4200-0216 | Countersink Φ8.0 | 1 |
| 17 | 4200-0217 | Hollow Reamer Φ8.0 | 1 |
| 4200-0218 | Extraction Screw Hexagonal 3.5mm Conical | 1 | |
| 18 | 4200-0219 | Tap Cortex 4.5mm | 1 |
| 4200-0220 | Tap Cancellous 6.5mm | 1 | |
| 19 | 4200-0221 | Bending Iron | 1 |
| 20 | 4200-0222 | Aluminium Box | 1 |
